Wi-Fi 6: The Next Step in Wireless Connectivity

What Is Wi-Fi 6?

Wi-Fi 6, also known as 802.11ax, operates on both 2.4 GHz and 5 GHz radio frequencies. A notable improvement over previous versions, it increases speed and capacity for next-generation applications that must transfer large volumes of data.

In legacy Wi-Fi networks, performance tends to degrade as more devices connect, resulting in lower speeds and increased latency. Wi-Fi 6 supports more clients per access point (AP). It delivers maximum speed and accessibility in high-density networks

Core Features of Wi-Fi 6

Wi-Fi 6 introduces a suite of advanced features that enhance wireless performance, especially in high-density environments. Each capability is purpose-built to address the demands of modern connectivity.

Orthogonal Frequency Division Multiple Access

Orthogonal Frequency Division Multiple Access (OFDMA) is a technique for load division. It splits network traffic into manageable segments by assigning specific frequencies and time slots to individual users. Devices with both low and high data demands benefit from this targeted allocation.

Regardless of payload size, Wi-Fi 6 dynamically uses Resource Units (RUs) to enable the AP to communicate with multiple devices simultaneously. It accomplishes this by dividing channels into sub-channels.

OFDMA enables multiple devices to share the same Wi-Fi channel simultaneously. The lower latency for uplink and downlink traffic reduces delays and improves performance for both sending and receiving data. Minimizing bandwidth competition improves performance in high-density environments.

1024-QAM

This form of quadrature amplitude modulation (QAM) is an advanced modulation scheme that encodes 10 bits per symbol. It increases data throughput by handling speed bursts more efficiently.

Target Wake Time

Target wake time (TWT) allows an AP to schedule specific time slots for devices to wake up and exchange data. Outside of these planned periods, devices remain in sleep mode to conserve energy.

With this feature, devices transmit less frequently while still maintaining a reliable connection. TWT results in significant power savings.

Multiple-User MIMO

Multiple-user multiple-input and multiple-output (MU-MIMO) uses multiple antennas to transmit radio signals to several devices simultaneously. Parallel transmission increases network capacity and improves performance in high-traffic environments.

Basic Service Set Coloring

Wi-Fi 6 introduces a feature called basic service set (BSS) coloring. BSS coloring allows an AP to assign a unique identifier called a “color” to its network. The color is included in the physical header of transmitted frames. It distinguishes signals from neighboring APs on the same frequency channel.

Using BSS coloring, devices can determine whether a transmission is from their network or a neighboring AP. The algorithm allows multiple APs to use a single radio frequency channel with greater capacity and less interference.

Security 

Wi-Fi Protected Access 3 (WPA3) is the latest encryption standard for Wi-Fi networks to transport secure data. Unlike earlier Wi-Fi generations, WPA3 introduces stronger protections for user data and network access. It is significantly harder for unauthorized parties to intercept or tamper with communications.

Previous Wi-Fi standards lacked this level of security. Its adoption creates a more robust and secure wireless environment.

Wi-Fi 6 vs. Previous Generations

As with other recent Wi-Fi releases, Wi-Fi 6 will be backward compatible. It will work with older devices while unlocking new capabilities for those that support the latest standard.

The following table compares the features of the Wi-Fi 6 standard with those of the previous releases:

Real-World Applications Classified by Features

Each key feature of Wi-Fi 6 supports specific real-world use cases, including:

The Future of Wireless Connectivity

Wi-Fi 6 is already a significant improvement over previous generations. Its adoption is expected to grow steadily in the coming years.

Upgrading your network infrastructure to Wi-Fi 6 provides several benefits. The AP can support more simultaneous connections, making it ideal for high-density environments. Performance remains smooth and consistent, even in environments with multiple connected devices.

Moreover, Wi-Fi 6 provides faster data transfer speeds and lower latency for time-sensitive applications. It also enhances overall security and improves general network performance.
